0i/0i Mate - Model C Connection manual (Function) Page 969

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

14. MEASUREMENT

951

CAUTION

Set a radius value irrespective of whether the diameter

programming or the radius programming is specified.

6254 e value on X axis during automatic tool offset

e value during tool length automatic measurement

6255 e value on Z axis during tool automatic offset

[Data type] Two–word

Increment system IS–A IS–B IS–C Unit

Metric input 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

[Valid data range] 1 to 99999999

These parameters set the e value during automatic tool offset (T series)

or tool length automatic measurement (M series).

CAUTION

Set a radius value irrespective of whether the diameter

programming or the radius programming is specified.

[Unit of data]
