B–64113EN–1/01

9. SPINDLE SPEED FUNCTION

595

Whereas the Cs axis may stop at a machine position of 5.000 to 5.003 if

the Cs contour control mode is entered after rotation in the spindle speed

control mode.

In this case, the relationship between the machine coordinates and

machine position is adjusted by shifting the machine position of the Cs

axis by a pitch error compensation.

If the Cs axis coordinate setup request signal CSFI1 <G274#4> is set to

’1’ during synchronization control, P/S alarm 5346 occurs.

Be sure to set up the coordinates before starting synchronization control.

Manual handle interrupts are disabled during Cs axis coordinate setup.

External machine coordinate system shifting is disabled for the axis that

is undergoing Cs axis coordinate setup.

The mirror image signals MI1 to MI4 <G106> and a mirror image based

on the MIRx parameter <bit 0 of parameter No. 0012> are disabled for the

Cs axis coordinate setup function.

This function does not support bidirectional pitch error compensation.

P/S alarm No. 5346 is issued if an attempt is made to perform Cs axis

coordinate setup for the axis for which bidirectional pitch error

compensation is in effect.

FANUC AC SPINDLE MOTOR

ai/bi series PARAMETER

MANUAL (B–65280EN)

2.4 Cs Contour Control

Synchronization control

Manual handle interrupt

External machine

coordinate system

shifting

Mirror image

Bidirectional pitch error

compensation

Reference item
