0i/0i Mate - Model C Connection manual (Function) Page 1174

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1156
Function Section
M
series
T
series
AddressSymbolSignal name
Canned cycle
(M series)/canned
cycle for hole
machining (T series)
Tapping signal TAP F001#5 f f
11.6
Servo off
(mechanical handle)
Servo off signals SVF1 to SVF4 G126 f f
1.2.8
Servo rotational
speed check
Servo rotational speed check enable
signal
SVSCK1 to SVSCK4 G349#0 to #3 f f
2.10
Servo rotational
speed check
Servo rotational speed too–low alarm
signal
TSA1 to TSA4 F349#0 to #3 f f
2.10
Cycle start/feed hold
Cycle start signal ST G007#2 f f
5.1
Cycle start/feed hold
Feed hold signal *SP G008#5 f f
5.1
Cycle start/feed hold
Automatic operation signal OP F000#7 f f
5.1
Cycle start lamp signal STL F000#5 f f
Feed hold lamp signal SPL F000#4 f f
Cs–axis coordinate
Cs–axis coordinate establishment
request signal
CSFI1 G274#4 f f
9.8.2
Cs–axis coordinate
establishment
function
Cs–axis coordinate establishment
alarm signal
CSFO1 F274#4 f f
9.8.2
function
Cs–axis coordinate establishment
status signal
CSPENA F048#4 f f
Cs contour control
Cs contour control change signal CON G027#7 f f
9.8.1
Cs contour control
Cs contour control change completion
signal
FSCSL F044#1 f f
9.8.1
Cs contour control
Cs contour control mode fine
acceleration/deceleration function
disable signal
CDF1 to CDF4 G127#0 to #3 f f
9.8.1
Outputting the
movement state of
Axis moving signals MV1 to MV4 F102 f f
1.2.5
movement state of
an axis Axis moving direction signals MVD1 to MVD4 F106 f f
1.2.5
Actual spindle speed
output
Actual spindle speed signals AR0 to AR15 F040, F041 f —
9.6
Constant surface
speed control
Constant surface speed signal CSS F002#2 f f
9.4
Spindle positioning
Spindle stop completion signal SPSTP G028#6 f —
9.7
Spindle positioning
Spindle unclamp signal SUCLP F038#1 f —
9.7
Spindle positioning
Spindle unclamp completion signal *SUCPF G028#4 f —
9.7
Spindle clamp signal SCLP F038#0 f —
Spindle clamp completion signal *SCPF G028#5 f —
Spindle orientation
Spindle orientation external stop
position command signals
SHA00 to SHA11
G078#0 to
G079#3
f f
9.12
Spindle orientation
Spindle orientation external stop
position command signals
SHB00 to SBH11
G080#0 to
G081#3
f f
9.12
