(1)Maintenance item names
The names of maintenance items are set up here. They can be
registered using either the corresponding menu or MDI keys.
1) Menu–based setup
1 To display the setting menu, place the cursor on the desired
item, and press the [ENTRY] soft key. There are two types of
setup menus: machine maintenance menu and CNC
maintenance menu.
2 Pressing the [MACHIN] or [NC] soft key displays a menu that
contains typical machine or CNC model names.
3 Place the cursor on the desired item and press the [SELECT]
soft key. Now press the [EXEC] soft key to return to the status
screen where the selected item name is set up.
4 Pressing the [CAN] soft key restores the previous screen.
5 Pressing the [MAINTE] soft key displays the status screen.
On the machine maintenance screen, items can be registered
according to the procedure below.
(a) Program–based registration
An item can be registered by executing a program in the
following format.
G10 L61 Px [n]
x : Registration number
n : Item name
[Alphanumeric character]
Format
Previous page
Next page
