0i/0i Mate - Model C Connection manual (Function) Page 598

Connection manual (Function)
B–64113EN–1/01
9. SPINDLE SPEED FUNCTION
580
#7 #6 #5 #4 #3 #2 #1 #0
CONG027
G028 GR2 GR1
MRDYAG070 SFRA SRVA CTH1A CTH2A
G127 CDF4 CDF3 CDF2 CDF1
#7 #6 #5 #4 #3 #2 #1 #0
F034 GR3O GR2O GR1O
F044 FSCSL
F094 ZP4 ZP3 ZP2 ZP1
The following describes major parameters.
In addition, parameters such as axis feedrate, acceleration/deceleration,
and display can be used. Also, digital servo parameters (No. 2000 or later)
for the Cs contour axis are not required to be set.
#7 #6 #5 #4 #3 #2 #1 #0
1006 ROTx
[Data type] Bit axis
Type of controlled axis
0 : Linear axis
1 : Rotation axis
NOTE
Inch/metric conversion cannot be made to the rotation axis.
The machine coordinate values are rounded in 0 to 360 deg.
Automatic reference position return (G28, G30) is made in
the manual reference position return direction and the move
amount does not exceed one rotation.
Set 1 as the rotation axis to the Cs contour control axis.
1020 Name of the axis used for programming for each axis
[Data type] Byte axis
Set the name of the program axis for each control axis, with one of the
values listed in the following table:
Axis
name
Set
value
Axis
name
Set
value
Axis
name
Set
value
Axis
name
Set
value
X 88 U 85 A 65 E 69
Y 89 V 86 B 66 – –
Z 90 W 87 C 67 – –
Signal address
Parameter
