2. PREPARATIONS FOR OPERATION
145
When G23 is switched to G22 while the tool is in a forbidden area, the
following results.
(1)When the forbidden area is internal to the limits, an alarm is generated
in the next move.
(2)When the forbidden area is external to the limits, an alarm is generated
immediately.
[Classification] Input signal
[Function] Selects whether stored stroke check 3 is checked.
[Use] When this signal is set to 1, the control unit operates as follows:
· The control unit does not check stored stroke check 3.
#7
G007
#6 #5 #4
RLSOT3
#3 #2 #1 #0
#7
BFA1300
#6
LZR
#5
RL3
#4 #3 #2 #1 #0
OUT
[Data type] Bit
OUT The area inside or outside of the stored stroke check 2 is set as a restricted
area.
0: Inside
1: Outside
RL3 Stroke check 3 release signal RLSOT3
0: The signal is disabled.
1: The signal is enabled.
LZR Checking of stored stroke check 1 during the time from power–on to the
manual position reference return
0: The stroke check 1 is checked.
1: The stroke check 1 is not checked
NOTE
When the absolute–position detector is being used, and the
reference position is already set at power–on, the stored
stroke check is checked immediately after the power is
turned on, regardless of the setting of this bit.
D Change from G23 to
G22 in a forbidden area
Signal
Stroke check 3 release
signal RLSOT3
<G007#4>
Signal address
Parameter
Previous page
Next page
