0i/0i Mate - Model C Connection manual (Function) Page 999

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

14. MEASUREMENT

981

[Classification] Input signal

[Function] Selects the tool offset number.

[Operation] When the mode for writing tool compensation is selected, the cursor is

automatically positioned on the tool geometry compensation number

selected by these signals.

A tool offset number is specififed by a 7–bit binary number. Numbers 0

to 63 correspond to the compensation number 1 to 64.

NOTE

This signal is available only when parameter QNI (No.

5005#5) =1.

[Classification] Input signal

[Function] Selects the mode for writing the shift amount for the workpiece coordinate

system.

[Operation] When this signal is turned to “1” in a manual operation mode, the mode

for writing the shift amount for the workpiece coordinate system is

selected. The control unit then automatically switches the screen

displayed to the WORK SHIFT screen and blinks the “OFST” status

display at the bottom of the screen to notify that the mode has been

changed to the mode for writing the shift amount for the workpiece

coordinate system. However, this is not performed when the mode for

writing tool compensation values is selected.

[Classification] Input signal

[Function] Automatically calculates and sets the shift amount for the workpiece

coordinate system.

[Operation] When this signal turns to “1” in the mode for writing the shift amount for

the workpiece coordinate system, it triggers the automatic calculation and

setting of the shift amount for the workpiece coordinate system.

Tool offset number

select signals

OFN0 to OFN5

<G039#0 to #5>

Workpiece coordinate

system shift value write

mode select signal

WOQSM <G039#6>

Workpiece coordinate

system shift value write

signal

WOSET <G040#7>
