0i/0i Mate - Model C Connection manual (Function) Page 1175

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1157

Function Section

series

AddressSymbolSignal name

Spindle serial

Torque limit command LOW signals

(serial spindle)

TLMLA G070#0 f f

9.2

Spindle serial

Torque limit command LOW signals

(serial spindle)

TLMLB G074#0 f f

9.2

Spindle serial

Torque limit command HIGH signals

(serial spindle)

TLMHA G070#1 f f

9.2

Spindle serial

Torque limit command HIGH signals

(serial spindle)

TLMHB G074#1 f f

9.2

Spindle serial

Clutch/gear signals (serial spindle)

CTH1A, CTH2A G070#3, #2 f f

9.2

Spindle serial

Clutch/gear signals (serial spindle)

CTH1B, CTH2B G074#3, #2 f f

9.2

Spindle serial

CCW command signals (serial spindle)

SRVA G070#4 f f

9.2

Spindle serial

CCW command signals (serial spindle)

SRVB G074#4 f f

9.2

Spindle serial

CW command signals (serial spindle)

SFRA G070#5 f f

9.2

Spindle serial

CW command signals (serial spindle)

SFRB G074#5 f f

9.2

Spindle serial

Orientation command signals

(serial spindle)

ORCMA G070#6 f f

9.2

Spindle serial

Orientation command signals

(serial spindle)

ORCMB G074#6 f f

9.2

Spindle serial

Machine ready signals (serial spindle)

MRDYA G070#7 f f

9.2

Spindle serial

Machine ready signals (serial spindle)

MRDYB G074#7 f f

9.2

Spindle serial

Alarm reset signals (serial spindle)

ARSTA G071#0 f f

9.2

Spindle serial

Alarm reset signals (serial spindle)

ARSTB G075#0 f f

9.2

Spindle serial

Emergency stop signals (serial spindle)

*ESPA G071#1 f f

9.2

Spindle serial

Emergency stop signals (serial spindle)

*ESPB G075#1 f f

9.2

Spindle serial

output/spindle

Spindle selection signals

(serial spindle)

SPSLA G071#2 f f

9.2

Spindle serial

output/spindle

analog output

Spindle selection signals

(serial spindle)

SPSLB G075#2 f f

9.2

analog output

Power line switch completion signals

(serial spindle)

MCFNA G071#3 f f

Power line switch completion signals

(serial spindle)

MCFNB G075#3 f f

Soft start/stop cancel signals

(serial spindle)

SOCNA G071#4 f f

Soft start/stop cancel signals

(serial spindle)

SOCNB G075#4 f f

Speed integral signals (serial spindle)

INTGA G071#5 f f

Speed integral signals (serial spindle)

INTGB G075#5 f f

Output switch request signals

(serial spindle)

RSLA G071#6 f f

Output switch request signals

(serial spindle)

RSLB G075#6 f f

Power line status check signals

(serial spindle)

RCHA G071#7 f f

Power line status check signals

(serial spindle)

RCHB G075#7 f f

Orientation stop position change

command signals (serial spindle)

INDXA G072#0 f f

Orientation stop position change

command signals (serial spindle)

INDXB G076#0 f f

Rotational direction command signals

for orientation stop position change

ROTAA G072#1 f f

for orientation stop position change

(serial spindle)

ROTAB G076#1 f f

Shortcut command signals for

orientation stop position change

NRROA G072#2 f f

orientation stop position change

(serial spindle)

NRROB G076#2 f f

Differential speed mode command

signals (serial spindle)

DEFMDA G072#3 f f

Differential speed mode command

signals (serial spindle)

DEFMDB G076#3 f f
