0i/0i Mate - Model C Connection manual (Function) Page 439

Connection manual (Function)
B–64113EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
421
NOTE
The functions usable in the advanced preview control mode
are listed below. When using an function other than those
listed below, turn off the advanced preview control mode
before using the function, and turn on the advanced preview
control mode upon completion of using the function.
S PMC–based axis control (usable in the advanced preview
control mode by setting bits 4 (G8R) and 3 (G8C) of
parameter No. 8004)
S Single direction positioning (M series)
S Polar coordinate command (M series)
S Helical cutting
S Rigid tapping (usable in the advanced preview control
mode by setting bit 5 (G8S) of parameter No. 1602. The
serial spindle parameter also needs to be set.)
S Program restart
S External deceleration
S Simple synchronization control
S Sequence number check stop
S Position switch (usable in the advanced preview control
mode by setting bit 3 (PSF) of parameter No. 6901)
S Cs contour control (usable in the advanced preview
control mode by setting bit 5 (G8S) of parameter No.
1602. The serial spindle parameter also needs to be set.)
S Constant surface speed control
S Spindle speed fluctuation detection
S Spindle synchronization control
S Custom macro B
S Optional–angle chamfering/corner rounding (M series)
S Direct drawing dimension input (T series)
S Inch/metric switching
S Programmable mirror image (M series)
S Mirror image for double turret (T series)
S Canned cycle (M series)
S Multiple repetitive canned cycle (T series)
S Multiple repetitive canned cycle 2 (T series)
S Hole machining canned cycle (T series)
S Automatic corner override (valid only for changing the
inside circular cutting feedrate)
S Scaling (M series)
S Coordinate system rotation
S Workpiece coordinate system
S Workpiece coordinate system preset
S Cutter compensation C (M series)
S Tool–nose radius compensation (T series)
S Corner arc
S Tool offset (M series)
S Y–axis offset (T series)
S Offset measurement value direct input B (T series)
