0i/0i Mate - Model C Connection manual (Function) Page 491

Connection manual (Function)
B–64113EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
473
The in–position check disable signal NOINPS <G023#5> specifies
whether to make in–position checks.
In addition, each of the individual–axis in–position check disable signals
NOINP1 to NOINP4 <G359#0 to G359#3> specifies whether to make
in–position checks for the corresponding axis.
If it is specified to make in–position checks, the CNC makes in–position
checks during deceleration and does not start executing the next
machining block until the corresponding axis gets in position.
[Classification] Input signal
[Function] Specifies whether to make in–position checks.
[Operation] If this signal is ”1”, the control unit behaves as follows:
No in–position check is made during deceleration regardless of the setting
of the NCI parameter (bit 5 of parameter No. 1601). When no in–position
check is made, the behavior of the control unit is the same as when the NCI
parameter (bit 5 of parameter No. 1601) = 1.
If this signal is ”0”, the control unit behaves as follows:
Whether to make in–position checks is determined according to the
setting of the NCI parameter (bit 5 of parameter No. 1601).
[Classification] Input signal
[Function] Each of these signals specifies whether to make in–position checks for the
corresponding axis.
[Operation] If one of these signals is ”1”, the control unit behaves as follows:
No in–position check is made on the corresponding axis during
deceleration regardless of the setting of the NCI parameter (bit 5 of
parameter No. 1601) and the state of the in–position check disable signal
NOINPS <G023#5>. When no in–position check is made, the behavior
of the control unit is the same as when the NCI parameter (bit 5 of
parameter No. 1601) = 1.
If one of these signals is ”0”, the control unit behaves as follows:
Whether to make in–position checks for the corresponding axis is
determined according to the setting of the NCI parameter (bit 5 of
parameter No. 1601) and the state of the in–position check disable signal
NOINPS.
7.2.5.3
In–position check
disable signal
General
Signal
In–position check
disable signal
NOINPS
<G023#5>
Individual–axis
in–position check
disable signals
NOINP1 to NOINP4
<G359#0 to #3>
