0i/0i Mate - Model C Connection manual (Function) Page 612

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

9. SPINDLE SPEED FUNCTION

594

Number Message Description

5346

RETURN TO REFERENCE

POINT

The Cs coordinate setup function was sus-

pended. Make a manual reference position

return.

1. An attempt was made to perform Cs axis

coordinate setup for the Cs axis for which

CSPEN = ’0’.

2. No position information has been trans-

ferred from the spindle amplifier.

3. The machine was brought to an emergen-

cy stop during coordinate setup.

4. Cs axis coordinate setup was started for

the Cs axis for which bidirectional pitch er-

ror compensation was in effect.

5. Cs axis coordinate setup was started for

the Cs axis whose servo was off.

If the CMR is greater than 1 (parameter No. 1820 > 2), the Cs axis may

move through several pulses’ worth of distance. This is intended to align

the Cs axis machine position to the least command increment. (1 to 9

pulses in terms of detection units if CMR = 10.)

If the Cs axis machine position meets the following condition, the Cs axis

moves by a pitch error compensation during coordinate setup.

|Nearest pitch compensation point – Cs axis machine position|

< pitch error compensation

Example:

5.000 5.010

Machine

coordinate

Machine

position

Pitch error compensation

Assuming that a pitch error compensation of +0.004 is specified for a

pitch error compensation interval of 10.000 degrees and a machine

coordinate of 5.000, the Cs axis will not stop at a machine position of

5.000 to 5.003.

Machine coordinate 4.999 → 5.000 → 5.001

Machine position 4.999 → 5.004 → 5.005

Alarm and message

Caution

CMR

Stored pitch error

compensation
