0i/0i Mate - Model C Connection manual (Function) Page 1211

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1193
Address
Referen
ce Item
M
series
T
series
Symbol Signal name
F014 to F015 2nd M function code signal M200 to M215 f f
8.3
F016 to F017 3rd M function code signal M300 to M315 f f
8.3
F022 to F025 Spindle speed code signal S00 to S31 f f
8.1
F026 to F029 Tool function code signal T00 to T31 f f
8.1
F030 to F033 2nd miscellaneousfunction code signal B00 to B31 f f
F034#0 to #2 Gear selection signal (output )
GR1O,GR2O,
GR3O
– f 9.3
F035#0 Spindle fluctuation detection alarm signal SPAL f f 9.5
F036#0 to F037#3S 12-bit code signal R01O to R12O f f 9.3
F038#0 Spindle clamp signal SCLP f –
9.7
F038#1 Spindle unclamp signal SUCLP f –
9.7
F038#2
Spindle enable signals
ENB2 f f
9.9
F038#3
Spindle enable signals
ENB3 f f
9.9
F040,F041 Actual spindle speed signal AR0 to AR15 f – 9.6
F044#1 Cs contour control switch completionsignal FSCSL f f 9.8.1
F044#2 Spindle synchronous speed control completion signal FSPSY f f
9.11
F044#3 Spindle phase synchronous control completion signal FSPPH f f
9.11
F044#4 Spindle synchronous control alarm signal SYCAL f f 9.11, 9.16
F045#0 Alarm signal (serial spindle) ALMA f f 9.2
F045#1 Speed zero signal (serial spindle) SSTA f f
9.2
F045#2 Speed detection signal (serial spindle) SDTA f f
9.2
F045#3 Speed arrival signal (serial spindle) SARA f f
9.2
F045#4 Load detection signal 1 (serial spindle) LDT1A f f
9.2
F045#5 Load detection signal 2 (serial spindle) LDT2A f f
9.2
F045#6 Torque limit signal (serial spindle) TLMA f f
9.2
F045#7 Orientationcompletionsignal (serial spindle) ORARA f f
F046#0 Power line switch signal (serial spindle) CHPA f f
F046#1 Spindle switch completionsignal (serial spindle) CFINA f f
F046#2 Output switch signal (serial spindle) RCHPA f f
F046#3 Output switch completionsignal (serial spindle) RCFNA f f
F046#4 Slave operation status signal (serial spindle) SLVSA f f
9.2, 9.15
F046#5
Signal for approximatespindle orientationwith a position
coder (serial spindle)
PORA2A f f
9.2, 9.15
F046#6
Signal for completionof spindle orientationwith a
magnetic sensor (serial spindle)
MORA1A f f
9.2, 9.15
F046#7
SIgnal for approximatespindle orientationwith a magnetic
sensor (serial spindle)
MORA2A f f
9.2, 9.15
F047#0
Signal indicatingthe status of the detected one-rotation
position coder signal (serial spindle)
PC1DTA f f
F047#1 Incrementalmethod orientationsignal (serial spindle) INCSTA f f
F047#4 Motor activation off status signal (serial spindle) EXOFA f f
