11. PROGRAM COMMAND

725

3455

#6 #5 #4 #3 #2 #1 #0

AXD

[Data type] Bit axis

AXD If a decimal point is omitted for an address with which a decimal point can

be used, the value is determined:

0 : In accordance with the least input increment.

1 : In millimeters, inches, or seconds. (calculator–type decimal point

input)

NOTE

1 This parameter is valid if bit 0 (DPI) of parameter No. 3401

is set to 0.

2 Because some addresses (such as R and K) are not related

to an axis, setting this parameter for all axes is not

equivalent to setting bit 0 (DPI) of parameter No. 3401 to 1.

3 This parameter cannot be used together with:

1) Macro executor

2) Macro call argument

3) Manual Guide 0i

Number Message Description

007 ILLEGAL USE OF DEC-

IMAL POINT

Decimal point “ · ” input error (A decimal

point was input after an address with

which it can not be used. Or multiple

decimal points were input.)

Modify the program.

Series 0i–C

OPERATOR’S MANUAL

(M series) (B–64124EN)

II.8.4 Decimal point programming

Series 0i–C

OPERATOR’S MANUAL

(T series) (B–64114EN)

II.8.3 Decimal point programming

Series 0i Mate–C

OPERATOR’S MANUAL

(M series) (B–64144EN)

II.8.4 Decimal point programming

Series 0i Mate–C

OPERATOR’S MANUAL

(T series) (B–64134EN)

II.8.3 Decimal point programming

Alarm and message

Reference item
