13. INPUT/OUTPUT OF DATA
929
Symptom Cause and corrective action
When an attempt is made to output
data to a power mate CNC:
Series 0i/0i Mate:
OUTPUT blinks con-
tinuously.
Power mate CNC :
No response is re-
turned. (Caution)
I/O Link confirmation signal IOLACK
is not set to 1.
A ladder program error, I/O Link as-
signment error may prevent.
When an attempt is made to read
data from a power mate CNC:
Series 0i/0i Mate:
LSK blinks continu-
ously.
Power mate CNC:
No response is re-
turned. (Caution)
When an attempt is made to output
parameters to a power mate CNC:
Series 0i/0i Mate:
OUTPUT blinks con-
tinuously.
Power mate CNC:
No response is re-
turned. (Caution)
PWE of the power mate CNC is set to
0.
To modify the power mate CNC pa-
rameters, PWE must be set to 1.
(Caution)
When an attempt is made to output
diagnostic data to a power mate
CNC:
Series 0i/0i Mate:
OUTPUT blinks con-
tinuously.
Power mate CNC :
No response is re-
turned. (Caution)
DWE of the power mate CNC is set to
0.
To enable the modification of power
mate CNC diagnostic data, DWE
must be set to 1.
(Caution)
