B–64113EN–1/01

1. AXIS CONTROL

110

8327 Torque difference alarm detection timer (two pair under synchronous control)

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

This parameter specifies the time between the servo preparation

completed signal SA <F000#6> becoming 1 and the torque difference

alarm detection function starting to check for a torque difference alarm

condition during simple synchronous control. The specified value is

rounded up to the nearest multiple of 16 ms.

(Example) If 100 is specified, 112 ms is assumed.

This parameter must be specified for the master axis. If the set value is

0, then 512 ms is assumed.

Number Message Description

213 ILLEGAL COMMAND IN

SYNCHRO–MODE

A move command was specified for the

slave axis of synchronous control.

214 ILLEGAL COMMAND IN

SYNCHRO–MODE

A command for coordinate system set-

ting or shift–type tool compensation

was executed during synchronous

control. Correct the program.

Number Message Description

213 ILLEGAL COMMAND IN

SYNCHRO–MODE

One of the following errors occurred

during simple synchronous control op-

eration:

(1) The program contains a move command

for the slave axis.

(2) A command for jog feed, manual handle

feed, or incremental feed was issued for

the slave axis.

(3) After power on, the command for auto-

matic reference position return was spe-

cified before a manual reference

position return had been performed.

(4) The difference in position error between

the master and slave axes exceeded

the value set in parameter 8313 or 8323.

Or, switching between synchronous mode

and asynchronous mode was performed dur-

ing automatic operation (when the automatic

operation signal (OP) is 1).

Alarm and message

T series

M series
