0i/0i Mate - Model C Connection manual (Function) Page 436

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

418

1783

Allowable speed difference for the speed difference based corner deceleration

function (linear acceleration/deceleration before interpolation)

[Data type] Word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotation axis 1 deg/min 6 to 15000 6 to 12000

A separate allowable feedrate difference can be set for each axis. The

allowable feedrate difference is set for each axis with this parameter.

Among the axes that exceed the specified allowable feedrate difference,

the axis with the greatest ratio of the actual feedrate difference to the

allowable feedrate difference is used as the reference to calculate the

reduced feedrate at the corner.

1784

Speed when overtravel alarm has generated during acceleration/deceleration

before interpolation

[Data type] Word

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotation axis 1 deg/min 6 to 15000 6 to 12000

Deceleration is started beforehand to reach the feedrate set in the

parameter when an overtravel alarm is issued (when a limit is reached)

during linear acceleration/deceleration before interpolation. By using

this parameter, the overrun distance that occurs when an overtravel alarm

is output can be reduced.

This setting can be applied also to rapid traverse blocks by setting bit 0

(OTR) of parameter No.7057. (M series)

NOTE

1 When 0 is set in this parameter, the control described above

is not exercised.

2 Use type–B linear acceleration/deceleration before

interpolation (by setting bit 0 (FWB) of parameter No.1602

to 1).

3 The control described above is applicable only to stored

stroke check 1.

4 The control described above is performed for the axes

specified in the current block and next block. By setting bit

5 (ODA) of parameter No. 7055, the control can be

performed just for the axis specified in the current block.

[Unit of data]

[Valid data range]

[Unit of data]

[Valid data range]
