0i/0i Mate - Model C Connection manual (Function) Page 287

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

269

If a correct reference mark interval cannot be detected for a cause, the tool

is positioned to the end point without establishing the reference position.

Therefore, the machine position, absolute coordinates, and machine

coordinates of the end point are set as if a G00 command without reference

position establishment operation were executed. However, the

intermediate tool path is different from the tool path obtained by

executing the G00 command.

Since the reference position is not established, reference position

establishment operation is performed again when the next G00 command

is specified.

Even when the CNC detects an illegal reference mark interval, it does not

issue the P/S090 alarm.

If the following conditions are satisfied, reference position establishment

operation is performed automatically:

<1> For an axis for which no reference position has been established,

feed axis direction selection signal +Jn or –Jn (G100, G102) is input

in jog mode.

<2> The move direction in <1> above matches the reference position

return direction set by bit 5 (ZMI) of parameter No. 1006.

<3> The specified axis is not in the following modes:

S Coordinate system rotation

S Mirror image (mirror image by signal or setting)

S Programmable mirror image (M series)

S Scaling (M series)

S Mirror image of facing tool posts (T series)

NOTE

If all the above conditions are not satisfied, reference

position establishment operation is not performed, and the

same operation as normal jog feed is performed.

The reference position establishment procedure is explained below.

<1> When the feed axis direction selection signal is set to 1, the tool starts

moving at the reference position return FL feedrate (parameter No.

1425).

<2> Upon detection of a reference mark on the scale, the tool is stopped

briefly then fed at the reference position return FL feedrate.

<3> Step <2> above is repeated until three or four reference marks are

detected on the scale. Then, the reference position is established,

and the reference position established signal (ZRF1, ZRF2, ZRF3,

etc.) is set to 1.

<4> The tool is fed in the direction selected by the feed axis direction

selection signal at the jog feedrate.

When the feed axis direction selection signal is set to 0 during steps <2>

to <4>, feed operation stops. When the feed axis direction selection signal

is set to 1 again, the reference position is established.

D When an illegal

reference mark interval

is detected

Reference position

establishment by jog

feed

D Activation condition

D Operation
