0i/0i Mate - Model C Connection manual (Function) Page 1209

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1191
Address
Referen
ce Item
M
series
T
series
Symbol Signal name
G166#1 Accumulated zero check signal ELCKZC f f
15.1
G166#2 Buffering disable signal (PMC axis control) EMBUFC f f
15.1
G166#3 Block stop signal (PMC axis control) ESBKC f f
15.1
G166#4 Servo off signal (PMC axis control) ESOFC f f
15.1
G166#5 Axis control temporary stop signal (PMC axis control) ESTPC f f
15.1
G166#6 Reset signal (PMC axis control) ECLRC f f
15.1
G166#7 Axis control command read signal (PMC axis control) EBUFC f f
15.1
G167#0 to #6 Axis control command signal (PMC axis control) EC0C to EC6C f f
15.1
G167#7 Block stop disable signal (PMC axis control) EMSBKC f f
15.1
G168,G169 Axis control feedrate signal (PMC axis control) EIF0C to EIF15C f f
15.1
G170 to G173 Axis control data signal (PMC axis control) EID0C to EID31C f f
15.1
G178#0 Auxiliary function completionsignal (PMC axis control) EFIND f f
15.1
G178#1 Accumulated zero check signal ELCKZD f f
G178#2 Buffering disable signal (PMC axis control) EMBUFD f f
G178#3 Block stop signal (PMC axis control) ESBKD f f
G178#4 Servo off signal (PMC axis control) ESOFD f f
G178#5 Axis control temporary stop signal (PMC axis control) ESTPD f f
G178#6 Reset signal (PMC axis control) ECLRD f f
G178#7 Axis control command read signal (PMC axis control) EBUFD f f
G179#0 to #6 Axis control command signal (PMC axis control) EC0D to EC6D f f
G179#7 Block stop disable signal (PMC axis control) EMSBKD f f
G180,G181 Axis control feedrate signal (PMC axis control) EIF0D to EIF15D f f
G182 to G185 Axis control data signal (PMC axis control) EID0D to EID31D f f
G192 Each-axis VRDY OFF alarm ignore signal IGVRY1 to IGVRY4 f f 2.8
G198 Position display neglect signal NPOS1 to NPOS4 f f 12.1.10
G199#0 Manual handle feed generator selection signals IOLBH2 f f
16.1
G199#1 Manual handle feed generator selection signals IOLBH3 f f
16.1
G200 Axis control superimposed command signal EASIP1 to EASIP4 f f 15.1
G274#4 Cs–axis coordinate establishment request signal CSFI1 f f 9.8.2
G349#0 to #3 Servo rotational speed check enable signal
SVSCK1 to
SVSCK4
f f 2.10
G359#0 to #3 Each axis in–position check disable signal NOINP1 to NOINP4 f f 7.2.5.3
F000#0 Rewinding signal RWD f f 5.2
F000#4 Feed hold lamp signal SPL f f 5.1
F000#5 Cycle start lamp signal STL f f 5.1
F000#6 Servo ready completionsignal SA f f 2.2
F000#7 Automatic operation signal OP f f 5.1
F001#0 Alarm signal AL f f 2.4
F001#1 Resetting signal RST f f 5.2
F001#2 Battery alarm signal BAL f f 2.4
