13. INPUT/OUTPUT OF DATA

907

3201

NPE

N99

#4 #3 #2

REP

RAL

RDL

[Data type] Bit

RDL When a program is registered by input/output device external control

0 : The new program is registered following the programs already

registered.

1 : All registered programs are deleted, then the new program is

registered.

Note that programs which are protected from being edited are not

deleted.

RAL When programs are registered through the reader/puncher interface

0 : All programs are registered.

1 : Only one program is registered.

REP Action in response to an attempt to register a program whose number is

the same as that of an existing program

0 : An alarm is generated.

1 : The existing program is deleted, then the new program is registered.

Note that if the existing program is protected from being edited, it is

not deleted, and an alarm is generated.

N99 With an M99 block, when bit 6 (NPE) of parameter No. 3201 = 0, program

registration is assumed to be:

0 : Completed

1 : Not completed

NPE With an M02, M30, or M99 block, program registration is assumed to be:

0 : Completed

1 : Not completed

3202

#6 #5 #4

NE9

#3 #2 #1 #0

NE8

[Data type] Bit

NE8 Editing of subprograms with program numbers 8000 to 8999

0 : Not inhibited

1 : Inhibited

The following edit operations are disabled:

(1)Program deletion (Even when deletion of all programs is specified,

programs with program numbers 8000 to 8999 are not deleted.)

(2)Program output (Even when outputting all programs is specified,

programs with program numbers 8000 to 8999 are not output.)

(3)Program number search

(4)Program editing after registration

(5)Program registration

(6)Program collation

(7)Displaying programs
