0i/0i Mate - Model C Connection manual (Function) Page 806

Connection manual (Function)
11. PROGRAM COMMAND
B–64113EN–1/01
788
5421 Scaling magnification for every axis
This parameter can be set at “Setting Screen.”
[Data type] Two–word axis
[Unit of data] 0.001 or 0.00001 times (Selected using SCR, #7 of parameter No. 5400)
[Valid data range] *999999 to *1, 1 to 999999
This parameter sets the scaling magnification for every axis.
Number Message Description
141 CAN NOT COMMAND
G51 IN CRC
G51 (Scaling ON) is commanded in the
tool offset mode.
Modify the program.
142 ILLEGAL SCALE RATE Scaling magnification is commanded in
other than 1 – 999999.
Correct the scaling magnification set-
ting (G51 P
p
, or parameter 5411 or
5421).
143 SCALED MOTION DATA
OVERFLOW
The scaling results, move distance,
coordinate value and circular radius ex-
ceed the maximum command value.
Correct the program or scaling magnifi-
cation.
Series 0i–C
OPERATOR’S MANUAL
(M series) (B–64124EN)
II.14.7 Scaling (G50, G51)
Series 0i Mate–C
OPERATOR’S MANUAL
(M series) (B–64144EN)
II.14.7 Scaling (G50, G51)
D Scaling magnification for
every axis
Alarm and message
Reference item
