0i/0i Mate - Model C Connection manual (Function) Page 861

Connection manual (Function)
B–64113EN–1/01
12. DISPLAY/SET/EDIT
843
The screen is not cleared if an alarm is issued.
WARNING
Pressing any key while the screen is being cleared restores
the screen. Do not press the , , or key to
restore the screen.
ALTER
INSERT
DELETE
[Classification] Input signal
[Function] Enables or disables the automatic screen erase function. This signal is
used to switch the control mode.
[Operation] When this signal is set to 0, the control unit:
· Enables the automatic screen erase function.
When this signal is set to 1, the control unit:
· Disables the automatic screen erase function, displays the screen, and
initializes the timer.
#7 #6 #5 #4 #3 #2 #1 #0
G062 *CRTOF
3123 Screen display timeout
[Data type] Bytes
[Unit of data] Minutes
[Valid data range] 1 to 255
This parameter specifies the period that must elapse before erase screen
display is applied. If 0 is set, the screen is not cleared.
D Alarm
Signal
Automatic erase screen
display cancel signal
*CRTOF <G062#1>
Signal address
Parameter
Previous page
Next page
