0i/0i Mate - Model C Connection manual (Function) Page 308

Connection manual (Function)
5. AUTOMATIC OPERATION
B–64113EN–1/01
290
#7 #6 #5 #4 #3 #2 #1 #0
G046
F004
SBK
MSBK
#7
SBV6000
#6 #5
SBM
#4 #3 #2 #1 #0
[Data type] Bit
SBM Custom macro statement
0: Not stop the single block
1: Stops the single block
If you want to disable the single blocks in custom macro statements using
system variable #3003, set this parameter to 0. If this parameter is set to 1,
the single blocks in custom macro statements cannot be disabled using
system variable #3003. To control single blocks in custom macro
statements using system variable #3003, use bit 7 (SBV) of parameter No.
6000.
NOTE
This bit is invalid when bit 0 (NOP) of parameter No. 6000
is set to 1. (M series)
SBV Custom macro statement
0 : Not stop the single block
1 : Stops the single block
To control single blocks in custom macro statements using system
variable #3003, use this parameter to enable or disable single blocks in
custom macro statements.
This bit is valid when bit 5 (SBM) of parameter No. 6000 is set to 0.
CAUTION
1 Operation in thread cutting
When the SBK signal turns to “1” during thread cutting,
operation stops after execution of the first non-thread
cutting block after the thread cutting command.
2 Operation in canned cycle
When the SBK signal turns to “1” during canned cycle
operation, the operation stops at each positioning,
approach, drilling and retreat instead of the end of the block.
The SPL signal turns to “1” while the STL signal turns to “0”,
showing that the end of the block has not been reached.
When the execution of one block is completed, the STL and
SPL signals turn to “0” and the operation is stopped.
Signal address
Parameter
Caution
