2.PREPARATION INSTALLATION B-75074EN/04

- 74 -

2.1 PREPARATION (FOR Windows XP)

This section describes the items you need to prepare when using

Windows XP as the OS. When the Web function is used, the Windows

2003 Server, which is the server OS of Windows XP, is needed.

2.1.1 Setting Up the TCP/IP (Basic Function) for Windows XP

NOTE

The user who makes the setting described in this

section must have the "administrator privilege".

Installing the TCP/IP protocol service

i CELL uses the network protocol called transmission control

protocol/internet protocol (TCP/IP) that enables communication over

the network.

Before installing i CELL, therefore, you must install the TCP/IP

protocol service on Windows XP.

You can check the TCP/IP is installed on Windows XP using the

following procedure. Select [Control Panel] → [Network and Dial-up

Connections] and activate [Local Area Connection]. Check whether

the [Local Area Connection Properties] list box contains "Internet

Protocol (TCP/IP)."

If the TCP/IP is not installed, install it using [Local Area Connection

Properties].

Refer to "Windows XP Setup Guide" for explanations about how to

install the TCP/IP.

Checking on localhost

The term localhost is a special host name used by the TCP/IP protocol

to indicate the host of interest. It is registered automatically when

Windows XP is installed. Deleting this setting hampers the normal

operation of i CELL.

Before installing the system described in this manual, check whether

localhost has been registered in the hosts file.

Supposing that Windows XP is installed in the "c:\windows" directory,

the hosts file is in the location stated below. (The directory where

Windows XP is installed is registered in the system environment

variable "windir". It can be checked by activating [System] on

[Control Panel].)

"c:\windows\system32\drivers\etc\hosts

Open this file with a test editor such as Notepad, and look for the

following line (usually it is at or near the beginning of the file).

127.0.01 localhost

If this line is not in the hosts file, add it.
