B-75074EN/04 INSTALLATION 2.PREPARATION

- 77 -

2.1.5 Registering the New User "IUSR_ICELL" (Web Function) for

Windows 2003 Server

To use the Web function, you need to register the new user

"IUSR_ICELL". If you do not use the Web function, you do not need

to make this setting.

NOTE

The user who makes the setting described in this

section must have the "administrator privilege".

1. Select [Start] → [Programs] → [Administrative Tools] and

activate [Computer Management].

2. On [Computer Management], select [System Tools] → [Local

Users and Groups] → [Users] and activate [New User] in

[Action].

3. Create a new user with specifying IUSR_ICELL for [User name]

and none for [Password] and turning the [Password never

expires] check box on.

2.1.6 Installing IE6.0 (Basic Function) for Windows XP

NOTE

The user who installs IE must have the

"administrator privilege".

IE 6.0 (Internet Explorer Version 6.0) is installed together with

Windows XP, so that IE 6.0 need not be installed additionally.
