B-75074EN/04 SETTING 5.CIMPLICITY VIEWER

- 205 -

If a different subnet mask is used, change it. Refer to “Windows Setup

Guide” for explanations about how to change a subnet mask.

Refer to the operator's manual for the Ethernet board in use for

explanations about how to set the subnet mask for an NC.

When a router is used between the server and viewer PCs

- Setting the router IP address

When using a router between the server and viewer PCs, you need to set

the default gateway address for each PC and the router IP address for

each NC. Set the IP address of the router as the default gateway address

and router IP address.

Because similarly to the server PC, the viewer PC uses

FOCAS2/Ethernet to communicate with NCs, you need to set up IP

routing for the router.

Server

Route

Viewer

Network A

Network B

IP address for

network B:

192.168.2.99

IP address

192.168.1.30

Subnet mask

255.255.0.0

Default gateway address

192.168.1.99

IP address

192.168.1.31

Subnet mask

255.255.0.0

Router IP address

192.168.1.99

IP address

192.168.2.40

Subnet mask

255.255.0.0

Default gateway address

192.168.2.99

IP address for

network A:

192.168.1.99

IP routing setup is required.

Communication using

FOCAS2/Ethernet

Setting example for a network configuration in which a router is used
