The settings are as follows:

Control point name rule (2) Path point

No Items (default) Description ($MCNPATH$ is required.)

F_COM_ON

(FNC$MCNPATH$. F_COM_ON)

Communication enable instruction point name rule setting

Set the name rule for a point for instructing whether to

perform communication with the CNC to which CNC

Communication Mode is connected. Be sure to set this

item.

F_COM_COND

(FNC$MCNPATH$.F_COM_COND)

Communication status monitor point name rule setting

Set the name rule for a point for checking a response to a

communication enable instruction point. Be sure to set

this item.

F_COM_PSET_NOTIFY

(FNC$MCNPATH$.

F_COM_PSET_NOTIFY)

Point Setting Notification name rule setting

Set the name rule for a point for the notification of a power

ON/OFF check and a completion of data reading. Be sure

to set this item.
