B-75074EN/04 SETTING 2.BASIC FUNCTIONS

- 135 -

Serve

Route

Serve

NC NC

The serve

PC and NCs

belong to different

networks, with a router

connecting the PC and

NCs.

The serve

PC and NCs belong to the same network.

Network A

Network B

Fig. 2.6.2(a) Network configuration (1) → C4 server enabled Fig. 2.6.2(b) Network configuration (2) → C4 server disabled

C4 Server

Timeout

This box lets you specify a timeout value (in counts) to

decide whether to turn off the NC power. This box can

be set only when the Enable C4 Server check box is

checked.

Use a default value of 2.

Retry Count

This box lets you specify how many times

communication with the NC is to be attempted after a

request for communication is rejected.

Use a default value of 5.

Re-connection

Communication

Error

This box lets you specify whether to make a

reconnection automatically and a reconnection method

if a communication error occurs for a poor

communication line quality. This box can be set only

when the Enable C4 Server check box is checked.

Check Disable (default).

- Disable

Does not make a reconnection automatically.

- Enable

Makes a reconnection automatically. When the quality

of the communication line is poor, another error can

occur soon even if Enable is checked and a

reconnection is made. If a communication error occurs

frequently, do not reply on the reconnection function

but improve the quality of the communication line. Note

that you may be unaware of frequently occurring errors

if Enable is checked. If a reconnection is made using

this function, the log "Retry Connection(1)" is created in

the "CimCNC connection error log".

- Select by Point

Specifies whether to make a reconnection by using the

value of the point FNCmmmpp.F_COM_RETRY (with

mmm representing a 3-digit machine number and pp

representing a 2-digit path number). If a communication

error occurs, i CELL sets the point to True. To make a

reconnection, set the point to False. If a reconnection is

made using this function, the log "Retry Connection(2)"

is created in the "CimCNC connection error log". When

using this function, the user needs to add a script that

monitors the point and sets the point to False when the

point is set to True.

Retry Interval

This box lets you specify an interval between retries for

communication with the NC to be made after a request

for communication is rejected.

Use a default value of 500.
