B-75074EN/04 SETTING 5.CIMPLICITY VIEWER

- 221 -

5.3 SETTING

This section describes the items you set using the i CELL

"CIMPLICITY VIEWER Setting Screen" on the server and viewer

PCs.

5.3.1 Procedure for Setting the Server PC

NOTE

The user who makes the setting described in this

subsection must have the administrator privilege.

Terminating the i CELL project

If the i CELL screen is displayed, use the [Quit] button on the main

menu to close the screen. If the × button at the upper-right corner of the

CimView screen is clicked or [Quit] in the [File] menu on the CimView

screen is executed to close the screen, you cannot make normal setting.

Then, terminate the i CELL project.

When you want to change an item that has already been set on the

CIMPLICITY VIEWER Setting Screen, close the i CELL screen and

terminate the i CELL project on all viewer PCs.

Backup

Execute “Backup & Restore” in program group “CIMPLICITY i

CELL” and create a backup file with specifying “i CELL All”.

Checking the conditions for CIMPLICITY viewer operation

Check that the server and viewer PCs satisfy the conditions for

CIMPLICITY viewer operation, referencing Subsection 5.2.1,

"Checking the Conditions for CIMPLICITY Viewer Operation and

Communication."

Allocating available drives

Allocate available drives, referencing Subsection 5.2.2, "Allocating

Available Drives for Sharing Directories."

Setting for sharing the server PC (when Windows XP is used)

Make a setting for sharing the i CELL installation directory and NC

program directory according to Subsection 5.2.3, "Setting for Sharing

the Server PC".

Starting the viewer PC

A communication test with the viewer PC will be performed during

setup of the server PC on the i CELL CIMPLICITY VIEWER Setting

Screen. Start the viewer PC in advance.
