5.CIMPLICITY VIEWER SETTING B-75074EN/04

- 202 -

5 CIMPLICITY VIEWER

This chapter describes how to use i CELL on the CIMPLICITY viewer.

5.1 OVERVIEW

You can also use all i CELL functions on the CIMPLICITY viewer.

Information on an NC connected to the server PC can be displayed on

the viewer PC.

Before using i CELL on the CIMPLICITY viewer, you need to set the

CIMPLICITY viewer using the i CELL CIMPLICITY VIEWER

Setting Screen. Set required items on both the server and viewer PCs.

NOTE

Before using the i CELL CIMPLICITY VIEWER

Setting Screen, be sure to create a backup of the

entities in the i CELL installation directory.

Note on installation

On the installation component select screen, the buttons indicating the

server and viewer components of the CIMPLICITY viewer are

displayed. When you want to install i CELL on the server PC of the

CIMPLICITY viewer or does not want to use the CIMPLICITY viewer,

select the “server” component.

When you want to install i CELL on the viewer PC of the CIMPLICITY

viewer, select the “viewer” component.

Network configuration

To use the CIMPLICITY viewer for i CELL, both the server and viewer

PCs must be able to communicate with NCs using FOCAS2/Ethernet.

When you want to use a router between the server and viewer PCs, you

need to set up IP routing. See Section 3.4, “NETWORK

CONFIGURATION,” in Part I, “GENERAL,” for details.

After setting up the CIMPLICITY viewer for i CELL, confirm that NCs

can be connected from the viewer PC according to the procedure

described in Subsection 5.4.1, “Checking Communication between the

Viewer PC and Each NC.”
