5.5.8.8 Communication reconnection instruction point
This is the point for instructing whether to make a reconnection if a
communication error occurs due to poor communication line quality. A
single point is required for each CNC.
Data Type
BOOL
Elements
1
Initial Value
False
Point Name
FNCxxx01.F_COM_RETRY (where xxx is a
machine number)
Detail
A value is set by the user.
If a communication error occurs, and the value
is True, a reconnection is made; if False, a
reconnection is not made.
5.5.8.9 Point Group Control Point
This is the point for controlling a Point Group, and each Point Group
requires a single Point Group Control Point.
A Point Group Control Point can be created with any name. For an
explanation of how to make Point Group Control Points, see Subsection
5.2.3, "Point Group".
Data Type
BOOL
Elements
1
Initial Value
True or False
Point Name
Default: FNCxxx01.F_POINT_GROUP
Any name:
Name for a machine = FNCxxx01.U_???
(where xxx is a machine number)
Name common to machines =
FNCSYSP.U_???
Detail
A value is set by the user.
If the value is True, data is read from the points
related to this point; if False, data is not read
from the points.
