4.NC PROGRAM MANAGEMENT GENERAL B-75074EN/04

- 32 -

4.2.2 NC Program Transfer by Operating the NC

To transfer an NC program by operating the NC, you cannot specify the

directory path to a file on the personal computer on the NC. On the NC,

specify an NC program with the file name, file number, or NC program

number of the NC program.

NC program management associates the file name, file number, or NC

program number directed by the NC with a file stored on the personal

computer.

At this time, the file name, file number, or NC program number is used

as a key.

NC program management searches the files in the default directory for

the NC program to be transferred using the key. With

FOCAS2/Ethernet and the Data Server, however, the concepts of key

and relating files are not applicable.

There are restrictions on the method for specifying the file name, file

number, or NC program number and on available keys, depending on

the NC type and communication protocol.

See Appendix C, "EXAMPLES OF NC OPERATIONS" or CNC

Operator’s Manual for main methods for selecting an NC program by

operating the NC.

The following table lists restrictions on operations depending on the

communication function.

Restrictions depending on the communication function

Used key

Communication

function

NC program transfer type

File name

NC program

number

File number

Downloading by operating the NC B A B

DNC2

Uploading by operating the NC B A B

Downloading by operating the NC C B C

Reader/puncher

Uploading by operating the NC C C B

Downloading by operating the NC

FOCAS2/Ethernet

Uploading by operating the NC

The FTP file transfer function of embedded Ethernet

is used.

Downloading by operating the NC

Data Server

Uploading by operating the NC

The Data Server function (FTP client) is used for

transfer.

A : Available as a key

B : Unavailable as a key

C : Whether the key is available depends on the operated NC type.
