D.ERROR CODES APPENDIX B-75074EN/04

- 554 -

0x00060136 Write to the result file failed.

0x0006013a

A folder having the same name as a file is present.

The folder cannot be overwritten by the file.

0x00060200

There is a file or folder name format error.

Check the file or folder name.

0x00060201

A specified file or folder name cannot be found.

Check whether the file or folder is present.

0x00060202 Too many files are registered.

0x00060203

The same file name is already present.

Downloading by overwriting an existing program cannot be performed. Check bit 2 of NC

parameter No. 3201.

0x00060204

A specified file or folder is selected on the NC side.

Cancel the selection, then retry.

0x00060205

There is no program within a specified range.

Check whether a program is registered.

0x00060206

The NC program area is destroyed.

Check the contents.

0x00060207

NC data contains a syntax error.

Check the contents.

0x00060208

When the TV check is valid, a block containing an odd number of characters (including LF at the

end of the block) is detected.

0x000604f0

The NC power is turned off during communication over the Ethernet, or the Ethernet cable is

broken.

Check the power supply and cable.

0x000604ff(1)

A program cannot be deleted in the MDI mode.

Use a mode other than the MDI mode.

0x000604ff(2) A selected program cannot be deleted in a mode other than the EDT mode.

0x000604ff(3) A program cannot be selected when another program is already running.

0x00060505(1)

The 140 BP/S alarm condition has occurred in the NC.

It is impossible to perform downloading to a program selected in the NC.

0x00060505(2)

The 73 BP/S alarm condition has occurred in the NC.

It is impossible to perform overwrite-downloading to an existing program. Check bit 2 of NC

parameter 3201.

0x00060505(3)

The 72 BP/S alarm condition has occurred in the NC.

An attempt was made to register more programs than the maximum number of programs that

can be registered with the NC. Delete unnecessary programs.

0x00060505(4) It is impossible to upload a program that is not in the NC.

0x00060505(5) It is impossible to select a program that is not in the NC.

0x00060505(6) It is impossible to delete a program that is not in the NC.

0x00060507

An NC program cannot be deleted because the memory protection key is on.

Turn off the memory protection key.

0x00060508

If the 70 BP/S alarm condition occurs in the NC:

The memory depleted in the NC when a program was being downloaded.

Delete unnecessary programs, and try to download the program again.

0x0006050b

A specified series number is incorrect.

Specify a correct series number.

0x0006050c

A program cannot be downloaded in the MDI mode.

Put the NC in the EDT or MEM mode.

Other errors (0x10010000 to 0x1009ffff)

0x10010003

The PC memory was depleted during execution.

Terminate unnecessary applications or increase the size of the virtual memory to allocate more

memory.
