3.MAIL SETTING B-75074EN/04

- 190 -

Conditions for applying the settings of one machine to all other machines

For the settings of one machine to be applied to all other machines, the

following conditions must be satisfied.

<1> All points (trigger and message points) used in the Mail Send

Configuration dialog box are in the format

FNCxxxyy.<data-type>, and the same machine number is

specified for all the points.

<2> The data type for the points used in the Mail Send Configuration

dialog box is registered for all other machines.

In the format stated above, xxx is a three-digit machine number, and yy

is a two-digit series number. <data-type> represents a data type that the

NC has; for example, F_AL represents an NC alarm signal.

In the Mail Send Configuration dialog box, a point that is not in this

format can also be set up for a machine. In this case, however, its setting

cannot be applied to other machines.

Example)

Assume the following points are registered for each machine.

Machine Point

1.MCN1 FNC00101.F_AL, FNC00101.F_ALARM0

2.MCN2 FNC00201.F_AL, FNC00201.F_ALARM0

3.MCN3 FNC00301.F_AL

If you already set up the trigger point FNC00101.F_ALand the message

point FNC00101.F_ALARM0 in the Mail Send Configuration dialog

box, the settings can be applied to the machines MCN1 and MCN2, but

not to the machine MCN3 (because FNC00301.F_ALARM0 has not be

registered for MCN3).
