B-75074EN/04 SETTING 2.BASIC FUNCTIONS

- 157 -

Masks of Sub

Programs

It is possible to disable transmission of subprograms even

if their calling is found. Subprograms can be specified in

units of 1000. It is possible to specify, for example, that

subprograms 8000 to 8999 and 9000 to 9999 are not to be

sent because they are in NC memory.

1st Directory

Searching

Sub Program

2nd Directory

Searching

Sub Program

3rd Directory

Searching

Sub Program

Up to three directories can be specified as storage for

subprograms. Numbers 1 to 3 represent the order in which

the directories are searched through. To put another way, if

the subprograms having the same name are in the [1st

Directory Searching Sub Program] and [2nd Directory

Searching Sub Program], the one in [1st Directory

Searching Sub Program] is sent.

An entered directory name can be deleted by pressing the

backspace key.

Search Sub

Program from

Main

program's
