5.5.8 CNC Connection Control Points

This subsection describes the points for controlling the operation of CNC

Connection and for monitoring the operation state.

Of these points, a single point necessary for a project can be created as

described in Subsection 5.3.2.1, "Init/Term Scripts General Settings".

If i

CELL is used, default points other than Point Setting Notification Points

are created in advance. Also, the single point necessary for each CNC or

for each path of a CNC is automatically created when the communication

settings for the machine are made.

5.5.8.1 Result Point

This is the point for storing the results of initiating CNC Connection, and a

single Result Point is necessary for a project.

In CNC Communication Mode, a Result Point may be created with any

name. For an explanation of how to create a Result Point, see Subsection

5.3.2.1, "Init/Term Scripts General Settings".

Data Type

INT

Elements

Initial Value

-1

Point Name

FNCSYSP.F_NCC_STATUS, or any name

Detail

A value is set by CNC Connection.

When the initiation process for CNC

Connection terminates, a result will be set. If

operation is normal, 0 is set; if an error such as

"no setting file found" occurs, a positive error

code is set.
