F.SETTING UP PC APPENDIX B-75074EN/04

- 586 -

F.2 SETTING UP FTP SERVER

This section explains how to set up an FTP server on the PC.

NOTE

If the OS is Windows NT, see subsection F.2.1

written for Windows NT. If the OS is Windows 2000,

see subsection F.2.2 written for Windows 2000.

F.2.1 Peer Web Services for Windows NT

Installing Per Web Services

1 Select [Start] > [Settings] > [Control Panel] > [Network].

2 In the [Network] dialog box, select the [Service] tag.

3 Check if "Microsoft Peer Web Server" exists in [Network

Services]. If "Microsoft Peer Web Server" does not exist, it needs

to be installed. So, click the [Add] button. If "Microsoft Peer Web

Server" exists, an FTP server needs to be additionally installed.

Select [Start] > [Programs] > [Microsoft Peer Web Services] >

[Peer Web Services Setup], then proceed to 5.

4 When you click the [Add] button, the [Select Network Service]

dialog box appears. Select "Microsoft Peer Web Server" then click

the [OK] button.

5 The [Peer Web Services Setup] dialog box appears. In [Options],

check "Internet Service Manager" and "FTP Service". (Check

other services as required.) After checking the services, click the

[OK] button.

6 The [Publishing Directories] dialog box appears. Set the root

directory to be accessed by FTP, then click the [OK] button.

7 The installation of "Microsoft Peer Web Services" starts.
