FANUC i-Cell Operators manual Page 55

Operators manual

Page of 739

/ 739

B-75074EN/04 GENERAL 4.NC PROGRAM MANAGEMENT

- 29 -

Communication protocol

Function

FOCAS2/

Ethernet

DNC2

Reader/

puncher

Data

Server

Management of NC program files in the NC memory by operating the personal computer

A list of NC programs held in the NC memory can be displayed on

the NC program management screen on the personal computer.

O O - O

Editing and referencing NC programs held in the NC memory.

An NC program held in the NC memory can be edited and

referenced.

A specified NC program can be automatically uploaded to the

personal computer for editing or referencing on the personal

computer. If an NC program on the personal computer has been

edited, download the NC program to the NC after confirmation.

O O - O

An NC program or directory held in the NC memory can be deleted

by operating the personal computer.

O O - O

In the NC memory, a directory is created from the personal

computer.

(*1)

- - O

An NC program name or directory name in the NC memory is

modified from the personal computer.

(*1)

- - O

Management of NC programs for multi paths

The NC programs of each path are managed under an arbitrary

directory.

O - - -

Management of NC program files on the personal computer by operating the NC

A list of NC programs on the personal computer can be displayed on

the NC screen.

(*2)

- O

(*3)

An NC program file on the personal computer can be deleted by

operating the NC.

(*2)

- O

(*3)

*1 This function can be used only with Series 30i/31i/32i.

*2 A function that can be executed by using the FTP file transfer

function of embedded Ethernet is available. However, NC

program management cannot be used. For details, refer to the

operator's manual of each NC.

*3 A function that can be executed by setting a Data Server as an FTP

client and setting a personal computer as an FTP server is

available. However, NC program management cannot be used. For

details, refer to the operator's manual of each Data Server.

NOTE

When the Reader/Puncher communication protocol

is used, some functions listed above may be

unavailable or an additional NC option may be

required, depending on the NC model.
