B-75074EN/04 APPENDIX D.ERROR CODES

- 553 -

0x00041024

Automatic ISO/EIA discrimination could not be executed for the NC program uploaded to the

computer.

The automatic ISO/EIA discrimination is made on the basis of the LF character included in a

hundred characters read from the beginning of the file. However, no LF character was sent

(0x0a: ISO; 0x80: EIA).

Check the contents of the data to be uploaded.

0x00041025

The data being uploaded does not contain any O number. A data upload with a file number

specified requires an O number in the data.

Check the data to be uploaded. Upload the data, specifying a file name instead of a file number.

0x00041026

The data being uploaded contains a character O or a colon (:), which is not followed by any

number.

Check the data to be uploaded.

0x00041028

In the automatic ISO/EIA discrimination of an NC program uploaded to the computer, an illegal

character was found.

Check the data to be uploaded.

0x0004102c

The upload or download data contains an illegal character.

For the upload data, the computer carries out an automatic ISO/EIA discrimination. The

characters may have been garbled because of a wrong communication setting.

For the download data, check whether the data in the computer is written in ASCII.

Ethernet communication errors (0x00060000 to 0x0006ffff)

0x00060102

A specified machine number is invalid.

Check the machine number registered in the Machine Configuration dialog box.

0x00060106 An Ethernet communication process was stopped because a request to stop it was received.

0x00060107

The NC with a specified machine number is already performing another process.

Wait for a while, and then rerun.

0x0006010c

An NC program number specified in a download or upload request is out of the valid range.

Check whether the NC program number is in a range between 1 and 9999 (1 to 99999999 when

8-digit NC program numbers are supported).

0x00060123

It is impossible to connect to the NC over an Ethernet network.

Check the connection of the Ethernet cable according to Subsection 2.6.1, "Setting up

Communication," in Part III, "Setting." Also check whether the IP address and TCP port number

match those set up in the NC.

0x00060128

It is impossible to connect to the C4 server.

Check the connection of the Ethernet cable according to Subsection 2.6.1, "Setting up

Communication," in Part III, "Setting." Also check whether the IP address and UDP port number

match those set up in the NC.

You need to make the UDP port set up in the NC match the entry of the services file on the PC.

Check the setting of FANUC_C4_SERVER according to Section 3.2, "Information to be

Automatically Saved to the TCP/IP Service File," in Part II, "Installation."

0x0006012a

An existence signal from the NC was interrupted.

It is likely that the NC power is off or an Ethernet cable has not been attached. So, processing is

impossible. Check the NC power and Ethernet cables.

0x0006012e

An NC program requested for downloading or DNC operation has no O number.

Check the contents of the NC program.

0x00060131

The number of valid characters for file paths is exceeded.

Check the number of characters.

0x00060132

A folder could not be created on the PC side.

Check the folder name.

0x00060133

A file having the same name as a folder is present.

The file cannot be overwritten by the folder.

0x00060134

There is a file or folder that cannot be uploaded or downloaded.

Check the results of uploading or downloading.

0x00060135

A file could not be created on the PC side.

Check the file name.
