B-75074EN/04 APPENDIX C.EXAMPLES OF NC OPERATIONS

- 547 -

Displaying the directory

1 Bring the NC into the EDIT mode.

2 Press function key <PRGRM>.

3 Press soft key [FLOPPY].

4 Press the <PAGE↑> or <PAGE↓> key to switch between pages.

Deleting an NC program

1 Bring the NC into the EDIT mode.

2 Press function key <PRGRM>.

3 Press soft key [DELETE].

4 Enter the file number "??".

5 Press function key <INPUT>.

6 Press soft key [EXEC].

Performing DNC operation of an NC program (file number)

When the NC program to be transferred is determined, the file number

is used as a key.

1 Bring the NC into the AUTO mode.

2 Enter the DNCI signal from the PMC to set the RMT mode.

3 Press function key <PRGRM>.

4 Press soft key [FL.SDL].

5 Press soft key [SELECT].

6 Enter the file number

"??".

7 Press function key <INPUT>.

8 Press soft key [EXEC].

9 When the cycle start is activated on the NC side, the automatic

operation starts.

Deleting an NC program

1 Bring the NC into the EDIT mode.

2 Press soft key [PRGRM].

3 Press soft key [DELETE].

4 Press soft key [PRGRM#].

5 Enter the file number

"??".

6 Press soft key [EXEC].
