B-75074EN/04 OPERATION 5.NC PROGRAM MANAGEMENT

- 257 -

For NC operation, refer to the operator's manual of each NC in the case

of FOCAS2/Ethernet, and see Appendix C.1, "DNC2", in the case of

DNC2.

NOTE

While the NC Program Management screen is

displaying a machine connected by DNC2, status

signals such as Activated and Alarm or machining

results cannot be obtained from the machine.

In this state, "Com.Hold" is displayed in the status

field of the overview menu screen.

(2) Reader/Puncher communication

The following can be performed by operating the NC.

• An NC program can be downloaded from a computer to the

NC.

• An NC program can be uploaded from the NC to a computer.

• A DNC operation can be carried out through the use of an NC

program in a computer.

• The File List in a computer can be displayed on the NC

screen.

• A file can be deleted from a computer.

For details of NC operations, see Appendix C.2,

"READER/PUNCHER."

(3) Data Server communication

The following can be performed just by operations on the NC

Program Management screen of the computer.

• Files of the personal computer can be downloaded to the

connection destination.

• Files of the connection destination can be uploaded to the

personal computer.

• The directory list and File List of the connection destination

can be displayed on the NC Program Management screen on

the personal computer.

• Files and directories of the connection destination can be

deleted.

• Files and directories of the connection destination can be

renamed.

• A directory can be created on the connection destination.

• A file of the connection destination can be edited or

referenced. A specified file can be automatically uploaded to

the personal computer and can be edited or referenced on the

personal computer. If a file on the personal computer is

rewritten at the time of editing, the file can be downloaded to

the connection destination after confirmation.

• A file of the connection destination can be copied or moved

to a directory.
