B.NC SETTING APPENDIX B-75074EN/04

- 518 -

B.5.3 Setting the FTP File Transfer Functions

This subsection describes the setting required when an FTP server is to

be set on a PC and the setting information is to be set as parameters for

the Data Server (to use the FTP file transfer function).

B.5.3.1 Parameter setting screen for the FTP file transfer function

This subsection describes the setting screen for operating the FTP file

transfer functions.

Procedure

1 Place the CNC in MDI mode.

2 Press function key

SYSTEM

3 Soft keys [EMBED] appear.

(When there is no soft keys, press the continue key.)

4 By pressing the [EMBED] soft key, the Ethernet Setting screen for

the embedded Ethernet port is displayed.

5 Press soft keys [COMMON] and [FTP TRANS] and then enter

parameters for the items that appear.

NOTE

1 The parameters for the embedded Ethernet port and

the parameters for the PCMCIA Ethernet card are

independent of each other.

2 If the [PCMCIA LAN] soft key is pressed, the

PCMCIA Ethernet card can be set up. However, the

card setup is carried out for maintenance and is not

necessary usually.
