B-75074EN/04 GENERAL 3.OPERATING ENVIRONMENT

- 21 -

3.3 PERSONAL COMPUTER/SOFTWARE

Operating system and related software

Using Windows NT

(A) When the Web function is used

All of <1> to <3> below are required.

<1> Microsoft Windows NT



Server 4.0 ServicePack 6a and later

<2> Microsoft Internet Information Server 4.0

(Included in Microsoft Windows NT



4.0 Option Pack. Obtain

this product from Microsoft.)

<3> Microsoft Internet Explorer 5.5 and later

(B) Cases other than (A) above

<1> or <2>, and <3> below are required.

<1> Microsoft Windows NT



Server 4.0 ServicePack 6a and later

(Microsoft Internet Information Server 4.0 required for the Web

function is not required.)

<2> Microsoft Windows NT



WorkStation 4.0 ServicePack 6a and

later

<3> Microsoft Internet Explorer 5.5 and later

NOTE

To use the i CELL with Windows NT4.0, the user

needs to belong to the Power Users group. To make

various settings on the setting screen, the user

needs to belong to the Administrators group.

Using Windows 2000

(A) When the Web function is used

All of <1> to <3> below are required.

<1> Microsoft Windows 2000



Server ServicePack 4 and later

<2> Microsoft Internet Information Server 5.0

(A full installation of <1> has <2> installed by default.)

<3> Microsoft Internet Explorer 6.0 and later

(B) Cases other than (A) above

<1> or <2>, and <3> below are required.

<1> Microsoft Windows 2000



Server ServicePack 4 and later

(Microsoft Internet Information Server 5.0 required for the Web

function is not required.)

<2> Microsoft Windows 2000



Professional ServicePack 4 and later

<3> Microsoft Internet Explorer 6.0 and later
