B-75074EN/04 USER CUSTOMIZE 2.ADDING SCREENS

- 385 -

2.2 SCREEN ADDITION

This chapter sequentially describes jobs required to add new screens.

NOTE

Before performing screen addition jobs (such as

screen creation and modification), be sure to back

up the i CELL. For the method of backup, see

Chapter 5, "BACKUP AND RESTORATION", in Part

II, INSTALLATION".

2.2.1 Determination of Basic Items

This subsection describes the basic items that need to be determined

before starting screen addition jobs (such as screen creation and screen

modification).

Determination of screen configuration

Determine a configuration for adding a screen. Two major methods are

available.

<1> A new function group is created, and a screen is added to the

group.

<2> A screen is added to an existing function group.

Depending on the number of screens (functions) to be added and on the

mechanism for screen switching, <1> is recommended because new

screens can be added more easily and less modifications to the

i CELL

are required.

Assuming that method <1> is used for screen addition, the method of

adding a standard screen and function screen is described below. When

method <2> is used, only a function screen is added. So, see the

relevant items only.

NOTE

Up to ten function groups can be used with the

current i CELL. However, eight function groups are

already used, so that only two function groups can

be added.
