2.ADDING SCREENS USER CUSTOMIZE B-75074EN/04

- 394 -

Setting of screen variables

Variable Description StnScr.cim FncScr.cim

FanucTabCtl_FirstSelected Tab number of the function group to which the screen

belongs. From top to bottom, the tab numbers are 0, 1,

2, ..., and 9.

(*1)

8 8

FanucTabCtl_SubID Value that does not duplicate any other screens of the

function group to which the screen belongs. The value is

0 for the screen that is displayed when the tab is

selected.

0 1

FanucTabCtl_ID Initial value: -1

(*2)

-1 -1

FanucTabCtl_TabSelected Initial value: -1

(*2)

-1 -1

FanucTabCtl_UsedOption Initial value: 0

(*2)

0 0

FNC_TBar_Menu Text character string for representing the name of the

function screen to which the screen belongs

User Function User

Function

FNC_TBar_ScrName Text character string for representing a screen name User standard

screen

User function

screen

FNC_MLine_DspMsg Text character string to be displayed. This character string

needs to be enclosed in double quotation marks (").

Initial value: "Message"

(*3)

”Message”

FNC_MsgFlag Whether a message is to be displayed is indicated.

0 (initial value): Not displayed,

Other than 0: Displayed

(*3)

0 0

FNC_ErrFlag Whether an error has occurred is indicated.

0 (initial value): Normal, Other than 0: Error

(*3)

0 0

FNC_DspFlag Whether screen display is being processed is indicated.

0 (initial value): Not being processed,

1: Being processed

(*3)

0 0

(*1) The newly usable value is 8 or 9.

(*2) Do not change the value. If a value other than the initial value is set,

the function switch tab can malfunction.

(*3) The value need not be changed. The values of these variables are

changed by a script or action to control the screen

(general-purpose objects for the i CELL). For details of the

general-purpose objects for the i CELL, see Section 2.3,

"GENERAL-PURPOSE OBJECTS FOR THE i CELL".

5 When all screen variables have been set, click the <OK> button,

then close the dialog box.

6 Save the screen.
