4.NC PROGRAM MANAGEMENT GENERAL B-75074EN/04

- 28 -

4.1 OVERVIEW

NC program management connects a personal computer as a NC

program file server to multiple NCs. NC program management also

allows connection with a Data Server or PC. For communication with a

Data Server or PC, the operating side needs to be an FTP client, and the

operated side needs to be an FTP server. When the connection target is

a PC, the same operation as for a Data Server can be performed by

operating NC program management.

The following table lists the functions available for each

communication function.

NOTE

When the communication function is a Data Server,

replace the "NC memory" in the following table with

"hard disk drive or ATA flash card built onto

(connected to) the Data Server board" or "ATA flash

card built onto (connected to) a Fast Data Server"

depending on the device to connect.

Communication protocol

Function

FOCAS2/

Ethernet

DNC2

Reader/

puncher

Data

Server

Sending and receiving of NC programs by operating the personal computer

An NC program on the personal computer can be downloaded to the

NC memory.

O O - O

The folders and the NC programs contained in the folders on the

personal computer can be downloaded in a batch to the NC

memory.

(*1)

- - -

When a main program is downloaded, the subprograms used by the

main program can automatically be retrieved and downloaded.

Moreover, multiple main programs can be registered in a list file,

and can be downloaded sequentially.

O - - -

NC programs can be uploaded from the NC memory to the personal

computer.

O O - O

The folders and the NC programs contained in the folders in the NC

memory can be uploaded in a batch to the personal computer.

(*1)

- - -

Sending and receiving of NC programs by operating the NC

By operating the NC, an NC program on the personal computer can

be downloaded to the NC memory.

(*2)

O O

(*3)

When a main program is downloaded by operating the NC, the

subprograms used by the main program can automatically be

retrieved and downloaded. Moreover, multiple main programs can

be registered in a list file, and can be downloaded sequentially.

(*2)

- O

(*3)

By operating the NC, NC programs can be uploaded from the NC

memory to the personal computer.

(*2)

O O

(*3)
