B.NC SETTING APPENDIX B-75074EN/04

- 512 -

B.5 SETTING THE EMBEDDED Ethernet FOR Series

30i/31i/32i-A

This section describes the items required to be set to operate the

embedded Ethernet function for Series 30i/31i/32i-A.

When using the FOCAS2/Ethernet function, see Subsections B.5.1 and

B.5.2.

When setting an FTP server on a PC and setting the setting information

as parameters for the Data Server (to use the FTP file transfer function),

see Subsections B.5.1 and B.5.3.

Refer to Section B.4, "Setting the FOCAS2/Ethernet of the Option

Board for Series 30i/31i/32i-A," for the option board.

B.5.1 Precautions to be Observed when using the FOCAS2/Ethernet

Functions for the First Time

CAUTION

When the embedded Ethernet function is used for

the first time, consult with your company’s network

administrator to determine the IP addresses and

other settings. Then, conduct a communications

test.

If incorrect IP addresses and other settings are set,

communications may be interfered with or the entire

network might be adversely affected.

NOTE

1 One of the following option functions is needed

when the FOCAS2/Ethernet functions are used:

Refer to Item "Ethernet boards or Data Server

Boards and CNC options," in Section 3.1 of Part I for

details.

2 There is a limit on the number of FOCAS2/Ethernet

clients connectable to one CNC using the

FOCAS2/Ethernet functions.

Refer to Note 2 in “Usable CNCs (When the

FOCAS2/Ethernet is used)” in Section 3.1 of Part I

for details.

3 If multiple application software products or multiple

personal computers access the CNC

simultaneously, the communication load on the

CNC can increase, resulting in decreased

communication speed and degraded CNC screen

display processing.
