B-75074EN/04 INSTALLATION 5.BACKUP AND RESTORATION

- 105 -

5.1.3 Confirming Backup Archive File Paths

A default backup archive file path is set up according to an option

selected in the "Select Backup/Restore Directory" frame. The default

path names used are as follows:

All of i CELL : %iCELL%\..\iCellAll. ibk

CimProject Only : %iCELL%\..\iCellCimPro. ibk

Any Directory : None; the user should specify a file name.

If "All of i CELL" or "CimProject Only" is selected, a backup archive

file is created by default in a directory one above the

directory %iCELL% where i CELL is installed.

To use a backup file name not specified by default, enter a desired

path name in the [File Path] text box. A backup file can be selected

using a selection dialog box displayed by clicking the small button at

the right of the text box.

NOTE

Before starting backup, make sure that there is an

enough free area on the hard disk. A rough

estimate of a backup archive file created at

installation is as follows:

All of i CELL : About 5 MB

CimProject Only : About 1 MB

Backup is performed during operation, a larger free

area is necessary, because result data is collected

during operation.
