C.EXAMPLES OF NC OPERATIONS APPENDIX B-75074EN/04

- 544 -

Examples of operations of FANUC Series 10/11/12/15

Downloading an NC program (file number)

The NC program to be downloaded is determined by the file number.

1 Bring the NC into the EDIT mode.

2 Press soft key [PRGRM].

3 Press soft key [READ].

4 Press soft key [FILE#].

5 Enter the file number

"??".

6 Press soft key [ALL].

Downloading an NC program (file name)

The NC program to be downloaded is determined by the file name.

1 Bring the NC into the EDIT mode.

2 Press soft key [PRGRM].

3 Press soft key [READ].

4 Press soft key [FILE NAME].

5 Enter the file name

"ABC".

6 Press soft key [ALL].

Uploading an NC program (file name)

When the NC program is saved, the file name is used as a key.

1 Bring the NC into the EDIT mode.

2 Press soft key [PRGRM].

3 Press soft key [PUNCH].

4 Press soft key [PRGRM#].

5 Enter the NC program number "????".

This NC program number becomes the file name

of the uploaded

program.

6 Press soft key [EXEC].
