4.REFERENCING THE DATABASE USER CUSTOMIZE B-75074EN/04

- 440 -

Procedure for writing data

The basic procedure for writing data to the database is described below.

NOTE

The i CELL database is a read-only database. Do

not write data, and do no modify the design and data

of the tables. Otherwise, the i CELL can

malfunction.

However, WKPCPlan - workpiece machining count

setting table, WKPCDspMcnCnd - progress status

display table, and WKPCDspLastState - machining

end state display table allow data modification and

addition. Do not modify the data of these tables and

do not add data to these table when the Workpieces

Process Result screen is displayed. Otherwise, the

screen may not be displayed normally.

For details, see Chapter 3, "DATABASE

SPECIFICATIONS".

1 Declare object variables.

Dim tWS As Workspace

Dim tCon As Connection

Dim tRdSt As Recordset

Dim tSQL As String

2 Create an ODBCDirect work space.

Set tWS = CreateWorkspace("", "admin", "", dbUseODBC)

Use the CreateWorkspace method for creation.

By specifying the definition constant dbUseODBC in the

argument Type, an ODBCDirect work space can be created.

When a work space is created with the CreateWorkspace method,

the method returns the Workspace object. By using the Set

statement, store the object in the object variable tWS.

3 As the cursor driver, specify the ODBC cursor library.

tWS.DefaultCursorDriver = dbUseODBCCursor

As a method target object, specify the created Workspace object

tWS.

4 Make a connection to the database.

Set tCon = tWS.OpenConnection(

"iCELL", dbDriverComplete, False,

"ODBC;DSN=iCELL;DATABASE=iCELL.mdb")

To make a connection, use the OpenConnection method.
