6.2 OPERATING ENVIRONMENT

6.2.1 Available CNCs

Available CNSs are the same as those when FOCAS2/Ethernet is used with

CELL.

Refer to "When the FOCAS2/Ethernet is used" in Section 3.1, "CNC", in

Chapter 3, "OPERATING ENVIRONMENT", in Part I, "GENERAL", in the

CELL Operator's Manual.

6.2.2 Ethernet Boards and CNC Options

Ethernet boards and CNC options are the same as those when

FOCAS2/Ethernet is used with i

CELL.

Refer to "Ethernet boards or Data Server boards and CNC options " in

Section 3.1, "CNC", in Chapter 3, "OPERATING ENVIRONMENT" in Part

I, "GENERAL", in the i

CELL Operator's Manual.

6.2.3 Network Configuration

The network configuration is the same as that when the FOCAS2/Ethernet is

used with i

CELL.

Refer to Section 3.3, "NETWORK CONFIGURATION", in Part I,

"GENERAL", in the i

CELL Operator's Manual.

6.2.4 Number of CNCs Connected

Using CNC Communication Mode requires that the basic order password

supplied with the installation CD be entered in the same way as with i

CELL.

Up to 75 CNCs can be connected using the order passwords of CNC

connection options.

6.2.5 CIMPLICITY HMI

A development server is required.
